RadioMaster XR1 Nano Multi-Frequency ExpressLRS Receiver – Ultra Compact Long Range ELRS RX

RadioMaster XR1 Nano Multi-Frequency ExpressLRS Receiver

The RadioMaster XR1 Nano is an ultra-compact, high-performance ExpressLRS (ELRS) receiver designed for pilots who need both flexibility and extreme reliability. By integrating the cutting-edge Semtech LR1121 transceiver, the XR1 offers exceptional sensitivity and range, whether you are flying in the standard 2.4GHz band for racing or switching to 900MHz for long-range exploration. It’s a versatile "do-it-all" receiver that fits into even the tightest micro-drone builds.

Why Pilots Choose the XR1

What makes the XR1 truly special is its Multi-Frequency capability. In the past, you had to choose between 2.4GHz and 900MHz when you bought your receiver. The XR1 changes the game by giving you the hardware to operate across bands, making it a perfect fit for pilots who fly everything from high-speed racing quads to massive, cinematic long-range rigs. It’s lightweight, robust, and designed to perform under the toughest conditions.

Modern Features for the Pro Pilot

The XR1 isn't just about raw range; it's designed to make your life easier:

• Built-in Wi-Fi: Update your firmware and configure your settings wirelessly through a PC or mobile device—no more plugging and unplugging cables!

• Ultra-Compact Size: Measuring just 20x13mm, it will disappear into the smallest frame.

• ESP32C3 MCU: A high-performance processor that ensures low latency and reliable signal processing.

• Telemetry Power: 100mW telemetry output gives you real-time data back to your radio, so you always know your battery health and signal quality.

Key Features

• Multi-Frequency Support: Compatible with 2.4GHz or Sub-G 900MHz setups.

• Semtech LR1121 Transceiver: Gen 3 technology for superior sensitivity and range.

• Wireless Configuration: Easy setup via built-in Wi-Fi and WebUI.

• Lightweight Design: Weighs only 1.0g (without antenna), perfect for weight-sensitive builds.

• Reliable Performance: Low-latency and high-refresh-rate support for ultimate control precision.

Technical Specifications

• MCU: ESP32C3

• RF Chip: Semtech LR1121

• Frequency: 2.4GHz or 900MHz

• Dimensions: 20mm x 13mm x 3mm

• Weight: 1.0g (receiver only)

• Working Voltage: 5V

• Connector: IPEX-1 (standard for easy antenna swaps)
